O.D. Range - Base Package: 2-7/8" to 5"
O.D. Range - Overall Capacity: 1" to 11"
Torque Range - Make-Up: 20,000 ft-lbs
Torque Range - Break-Out: 30,000 ft-lbs
Arm Spacing Adjustment: 2" to 10"
Dimensions: 34"W x 28"H x 33"D
Weight: 350 lbs

All of our machines feature the following:

• Safe and Easy to Operate
• Compact and Portable
• Instantly Converts between Make-Up and Break-Out Operation
• Built in Backup Arm
• Accurate Torque Control
• Easy Torque Adjustments
• Operates in Horizontal or Vertical Position
• Multiple Power Pack Options:
  • Diesel
  • Electric
  • Gasoline
  • Pneumatic/Air
  • Rig's hydraulic system
• Optional Accessories:
  • TorqueShark™ Torque Recording System (Click to learn more)
  • Reducer Package
  • Bit Breaker
  • Additional Links
  • Jaws for larger O.Ds
  • DPT – Drill pipe package
